CARACTERÍSTICAS DE HARDWARE
Interfaz 2× 10G Ethernet Ports (20G Aggregation Speed†)
Botones Reset
Fuente de Alimentación • 802.3bt PoE++
• 12V DC
Note：Power adapter is not included.
Consumo de Potencia 39W
Dimensiones 11.0 x 11.0 x 1.8 in (280 x 280 x 46.5 mm)
Antenas Internal Omni
• 2.4 GHz: 4× 4 dBi
• 5 GHz: 4× 5.5 dBi
• 6 GHz: 4× 5 dBi
Bluetooth V5.2
Montaje Ceiling / Wall Mounting (Kits Included)
CARACTERÍSTICAS INALÁMBRICAS
Coverage 200㎡ §
Clientes concurrentes 760+**
Estándares Inalámbricos IEEE 802.11 a/b/g/n/ac/ax/be
Frecuencia 6 GHz, 5 GHz, and 2.4 GHz
Tasa de Señal • 6 GHz: Up to 11520 Mbps
• 5 GHz: Up to 5760 Mbps
• 2.4 GHz: Up to 1376 Mbps
Funciones Inalámbricas • MLO
• 4K-QAM
• MU-MIMO (4x4 MU-MIMO DL/UL)
• HE320 (320 MHz Bandwidth)‡
• Mesh§
• Seamless Roaming(802.11k/v/r)△
• Automatic Channel Selection and Power Adjustment*
• BSS Coloring
• UL/DL OFDMA
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS
• Wireless Statistics
• Wireless Schedule
• Reboot Schedule
• RADIUS Accounting
• MAC Authentication
• Static IP/Dynamic IP
Seguridad Inalámbrica • PPSK
• VLAN
• Access Control
• Rogue AP Detection
• Captive Portal Authentication△
• Maximum number of MAC Filter: 4,000
• Wireless Isolation between Clients
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
Potencia de Transmisión • CE: <20 dBm (2.4 GHz, EIRP)
<23 dBm (5 GHz band 1&band 2, EIRP)
<30 dBm (5 GHz band 3, EIRP)
<23 dBm (6 GHz EIRP)
GESTIÓN
Omada App Yes
Restore & Backup Yes
Firmware update via Web Yes
NTP Yes
Gestión Centralizada • Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller
Acceso a la nube Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.
Alertas por Correo Electrónico Yes
LED de control ON / OFF Yes
Control de Gestión de Acceso MAC Yes
SNMP v1, v2c, v3
SSH Yes
Gestión basada en Web Yes
GENERAL
Peso Net Weight:1384.6g
Otros
Certificaciones CE, FCC, RoHS, IC
Contenido del Paquete • EAP783
• Installation Guide
• Ceiling/Wall Mounting Kits
Factores Ambientales • Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing
