CAMERA
Image Sensor 1/2.8'' CMOS
Lens 2.0±5%; Focal Length: 3.9mm±5%
Motion Range Pan Mechanical Range: 340° (360° Pan Coverage)
Tilt Mechanical Range: 60° (130° Tilt Coverage)
Night Vision IR LED (Up to 98 ft), Full-Color Night Vision
Lighting 2× Built-in Spotlights
Interface & Button 1× RESET Button
1× MicroSD Card Slot
Weatherproof Rating IP65
View Range 360° horizontal and 130° vertical
Resolution 2K 3MP (2304 × 1296 px)
VIDEO & AUDIO
Maximum Resolution 2304 × 1296 px
Frame Rate 15 fps
Video Compression H.264
Live View Yes
Image Enhancement 3DNR
WDR
Audio Input & Output Built-in Microphone and Speaker
Audio Communication Two-Way Audio with Noise Cancellation
Siren Volume 90 dB (Level measured at 4-inch/10-cm distance)
STORAGE
Local Storage MicroSD Card Slot on Camera (Up to 512 GB)
General Information about using MicroSD Cards >
Cloud Storage Tapo Care Cloud Storage Services (Subscription required)
VIDEO
Frame Rate 15 fps
Video Streaming 2K
Video Compression H.264
DETECTION and NOTIFICATIONS
AI Detection Motion detection
Person detection
Tamper detection
Activity Zones Yes
Output Notification System Notification
System Notification with Snapshot (Tapo Care Services)
AUDIO
Audio Communication Two-Way Audio
Audio Input & Output: Built-in Microphone and Speaker
NETWORK
Network Connectivity Connect via Wi-Fi
Wireless Connectivity IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
Wireless Security WPA/WPA2-PSK
RTSP Yes
ONVIF Yes
Standards and Protocols IEEE 802.11b/g/n
Security 128 bit AES encryption with SSL/TLS
Frequency 2.4 GHz
SECURITY
Security On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK
POWER
Power Source 12V DC Power Adapter
Input Voltage 100-240 V, 50/60 Hz
Output Voltage 12 V, 1 A (DC Power)
GENERAL
Smart Integration Google Assistant, Amazon Alexa
Weather Resistance IP65
System Requirements Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher
Mounting Options Ceiling-Mounted
Wall-Mounted
Pole-Mounted (Pole-Mounting loops required but not included)
Operating Temperature -30℃~60℃
Storage Temperature -40℃~60℃
Operating Humidity 10%~90%RH, Non-condensing
Storage Humidity 0~90%RH, Non-condensing
Dimensions 4.9 × 4.8 × 3.5 in (123.8 × 123 × 90 mm)
Package Contents Tapo C510W Camera
Power Adapter
Mounting Anchors
Mounting Screws
Bracket Screws
Mounting Template
Mounting Bracket
Waterproof Seal
Quick Start Guide
Certifications CE, FCC, RoHS, RCM
ACTIVITY NOTIFICATIONS
Input Trigger Person Detection, Motion Detection
Output Notification Snapshot(Tapo care), Clips(Tapo care)
HARDWARE
Button RESET Button
Indicator LED System LED
Adapter Input 100-240V, 50/60Hz
Adapter Output 12.0V/1.0A
Product Dimensions (W x D x H) 4.9 x 4.8 x 3.5 in. (123.8 x 123 x 90 mm)
