PERFORMANCE
Processor
AMD Ryzen™ 5 PRO 7535U (6C / 12T, 2.9 / 4.55GHz, 3MB L2 / 16MB L3)
Graphics
Integrated AMD Radeon™ 660M Graphics
Chipset
AMD SoC Platform
Memory
1x 16GB SO-DIMM DDR5-4800
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR5-4800
Storage
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Support
One drive, up to 2TB M.2 2280 SSD
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio™
Camera
HD 720p with Privacy Shutter
Microphone
2x, Array
Battery
46.5Wh
Power Adapter
65W USB-C® (2-pin)
DESIGN
Display
16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC
Touchscreen
None
Keyboard
Non-backlit, Spanish (LA)
Case Color
Black
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Pen
Pen Not Supported
Dimensions (WxDxH)
357.2 x 253.4 x 20.78 mm (14.06 x 9.98 x 0.82 inches)
Weight
Starting at 1.77 kg (3.90 lbs)
SOFTWARE
Operating System
None
Bundled Software
None
CONNECTIVITY
WLAN + Bluetooth
Qualcomm® Wi-Fi® 6E NFA725, 802.11ax 2x2 + BT5.3
WWAN
Non-WWAN
SIM Card
None
Ethernet
100/1000M (RJ-45)
NFC
None
Standard Ports
1x USB-A (Hi-Speed USB / USB 2.0)
2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one Always On
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0 and DisplayPort™ 1.4
1x USB-C® (USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 1.4
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Optional Ports (configured)
None
Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® L16 Gen 1 (AMD)
SECURITY & PRIVACY
Smart Card Reader
None
Security Chip
Discrete TPM 2.0 Enabled
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Physical Locks
Kensington® Nano Security Slot™, 2.5 x 6 mm
Other Security
Camera privacy shutter
MANAGEABILITY
System Management
DASH
SERVICE
Base Warranty
3-year, Courier or Carry-in
Included Upgrade
3Y Onsite upgrade from 3Y Courier/Carry-in
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ErP Lot 6/26
RoHS compliant
TCO Certified 10.0
Mil-Spec Test
MIL-STD-810H military test passed
