CARACTERÍSTICAS DE HARDWARE
Interface 2x 10Gbps Ethernet Ports (20G Aggregation Speed†)
Botón Reset
Fuente de Alimentación • 802.3bt (dual PoE inputs for hot backup)
• 12V/4.5A DC
Consumo de Energía 44 W (for PoE); 39W (for DC)
Dimensiones (W X D X H) 11 x 11 x 2.3 in (280 x 280 x 58.7 mm)
Antena • 2.4 GHz: 4× 4.0 dBi
• 5 GH: 4× 5.5 dBi
• 6 GHz: 4× 5.0 dBi
Bluetooth V5.2
Montaje Ceiling / Wall mouting (Kits included)
CARACTERÍSTICAS INALÁMBRICAS
Coverage 200㎡(2150ft²)§
Concurrent Clients 760+**
Estándares Inalámbricos IEEE 802.11 a/b/g/n/ac/ax/be
Frecuencia • 2.4 GHz
• 5 GHz
• 6 GHz
Tasa de Señal 1376 Mbps (2.4 GHz) + 8640 Mbps (5 GHz) + 11520 Mbps (6 GHz)
Funciones Inalámbricas • MLO‡
• 4K-QAM‡
• MIMO(2.4GHz: 4*4 SU-MIMO/MU-MIMO DL/UL; 5GHz: 4*4 SU-MIMO/MU-MIMO DL/UL; 6GHz: 4*4 SU-MIMO/MU-MIMO DL/UL)
• HE320 (320 MHz Bandwidth)‡
• PPSK△
• Mesh△
• Seamless Roaming△
• Rate Limit: Based on SSID/Client
• BSS Coloring
• UL/DL OFDMA
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS
• Wireless Statistics
• Wireless Schedule
• Reboot Schedule
• RADIUS Accounting
• MAC Authentication
• Static IP/Dynamic IP
Seguridad Inalámbrica WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Potencia de Transmisión <28 dBm (2.4 GHz)
<28 dBm (5G band 1&band 4)
<24 dBm (5G band 2&band 3)
<28 dBm (6 GHz)
Multi-SSID 24 (8 on each band)
ADMINISTRACIÓN
SNMP v1, v2c, v3
Otros
Certificacion CE, FCC, RoHS
Contenidos del Paquete • AP9778
• Installation Guide
• Ceiling/Wall Mounting Kits
Ambiente • Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;
